第四章 組合邏輯電路\
4.1 組合邏輯電路的分析方法
①寫邏輯式 ②化簡 ③寫真值表 ④分析
舉例:
半加法器
全加器
4.2 常用的組合邏輯電路
譯碼器
譯碼:將輸入的代碼「翻譯」成另外一種代碼輸出。和編碼器逆過程。
2線-4線譯碼器(74HC139)
3線-8線譯碼器(74HC138)
兩個2線-4線譯碼器接成的3線-8線譯碼器
P.111上
4線-16線譯碼器(74HC154)
用兩片3線-8線譯碼器74HC138組成4線-16線譯碼器
七段顯示譯碼器
編碼器
編碼:將一組編碼輸入的每一個訊號編成一個與之對應的輸出代碼。
普通編碼器:正常工作時只允許輸入一個編碼訊號,不允許同時輸入兩個以上的編碼輸入訊號,否則輸出將出現錯誤狀態。
優先編碼器:當同時有兩個以上的編碼輸入訊號時,只對其中優先權最高的一個進行編碼。
8線-3線優先編碼器
數據選擇器
從輸入的一組資料中選出一個送到輸出端
雙四選一資料選擇器(74HC153)
用兩個四選一資料選擇器接成的八選一資料選擇器
八選一數據選擇器(74HC151)
加法器
半加法器
全加器
數值比較器
一位數值比較器
多位數值比較器
原理:從高位比起,只有高位相等,才比較下一位。
4.3 組合邏輯電路的設計方法
1. 邏輯抽象 分析因果關係,確定輸入/輸出變量,原因-輸入,結果-輸出 定義邏輯狀態的含意(賦值),1、0具體意義 列出真值表 2. 從真值表寫出邏輯函數式 3. 選定裝置的類型 4. 對邏輯式化簡或變換 5. 從邏輯式畫出邏輯圖
選用中規模整合的常用組合邏輯電路
①選用資料選擇器
②選用譯碼器
4.4 組合邏輯電路中的競爭-冒險現象
競爭不一定有冒險,但冒險一定有競爭
相切的卡諾圈會產生冒險。消除方法:增加相切卡諾圈
