時序邏輯電路
時序邏輯電路的基本概念
三個基本方程
激勵方程組
狀態轉換方程組
輸出方程組
時序電路的特徵
由組合電路和儲存電路組成
由目前輸入變數和狀態決定電路的下一個狀態
輸出訊號由輸入訊號和電路狀態共同決定
時序電路
非同步時序電路
脈衝異步時序電路
電頻異步時序電路
同步時序電路
時鐘同步狀態機
時序邏輯電路功能表達
邏輯方程組
狀態轉換表
狀態轉換圖
時序圖
同步時序邏輯電路的分析
1.列出激勵方程組;狀態轉換方程組;輸出方程組
2.列出狀態轉換表,列出電路所有可能的現態
3.畫出狀態轉換圖
4.畫出時序圖
5.邏輯分析功能
同步時序邏輯電路的設計
1.由給定的邏輯功能建立原始狀態轉換圖和原始狀態轉換表
2.狀態化簡
3.為每個狀態指定一個特定的二進位代碼機狀態分配
4.選擇觸發器類型
5.確立激勵方程組與輸出方程組
6.畫出邏輯圖,檢查自校正能力
時序邏輯的可程式電路實現
在PLD中增加觸發器和回授連接,就可以實現時序邏輯
非同步時序邏輯電路的分析
1.列出各邏輯方程組
時脈訊號方程組
激勵方程組
狀態轉換方程組
輸出方程組
2.列出狀態轉換表
3.畫出狀態轉換圖與時序圖
4.邏輯功能分析
常用時序邏輯電路模組
暫存器
暫時存放二級制數位的時序邏輯元件
一類是由多位D觸發器並行組成的暫存器,資料是在時脈有效邊緣到來時存入的,另一類是由D鎖存器組成,資料是在時脈某個約定電平下存入的。
移位暫存器
單向移位暫存器:串入-串/並出單向移存器;串/併入--串出單向移存器
多功能雙向移位暫存器
計數器
運作時,從某一狀態開始完整循環一次所經歷的狀態數稱為----計數器的模M
非同步二進制計數器
同步二進位計數器
進位方法:遞增計數器的低位計滿後激勵高位觸發器翻轉的過程稱為計數進位
非同步清零和同步並行置數
74LVC161-典型整合同步二進位計數器
其他模數的計數器
N代表2的N次方的二進位計數器
N<M
回饋清零法
回饋置數法
N>M
同步級聯
非同步級聯
移位暫存器型計數器
環形計數器
扭環形計數器
