施工流程
二、拆除、新建牆體施工
設計師 、專案經理、業主、施工人員到現場
設計師畫出拆牆位置
拆除施工
設計師根據圖面現場畫出拆牆位置
現場施工人員
現場施工人員依照設計師畫的位置彈線
現場施工人員必須依彈線位置切除要拆牆體深度必須在2~3cm
現場施工人員拆必須用板子保護地面以免損傷地暖管
拆除完垃圾必須裝袋堆放整齊、並運送到指定垃圾堆放處
砌牆施工
設計師依圖現場放出要砌牆體位置
現場施工人員
現場施工人員依照設計師畫的位置彈線
現場施工人員必須依彈線位置吊垂直線
如遇門洞門洞過梁需以4*4角鋼、角鋼深入牆體不得少於20cm。
最頂面一排磚須斜放
如需砌加氣塊牆磚廚房衛浴牆面30公分以下需小紅磚墊底
牆體砌完必須達到平整垂直誤差不能超過1cm
包管必須用隔音棉包好所有下水管道
除鋪牆磚牆面外其餘全部刷牆面牆固、地固
專案經理設計先驗驗收
達到驗收標準通知業主、設計師進行驗收
通知業主進行驗收驗收合格進行下項工程
驗收不合格通知工人返工
驗收不合格通知工人返工
三、水、電、暖、空調改造施工
設計師 、專案經理、業主、施工人員到現場
設計師根據施工圖定位水、電、空調
設計師拍水路電路走照片留底
現場施工人員
空調安裝
水、電依定位刻槽、槽必須垂直
低盒必須安裝方正
水路做完必須打壓
專案經理
配合工人負責上料及鋪磚輔材
日常巡場
檢查驗收
四、防水工程施工
瓦工打墊層
施工人員
施工區域清理乾淨平整
廚房陽台地面滿做、牆面距地30CM用複合卷材做一遍
浴室地面滿做、牆面距地180CM用複合卷材做一遍
地面刷東方雨虹或西卡塗料一遍
複合卷材做的地方不能有空鼓
做完等塗料和捲材完全乾了之後做24小時閉水試驗
設計師 、專案經理、業主、施工人員到現場驗收。驗收合格須簽字確認。
五、鋪磚工程施工
設計師 、專案經理、業主、施工人員到現場
設計師
設計師依施工圖向施工人員交底
設計師時常巡場
現場施工人員
必須依照一米線及整體標高鋪設
所有磁磚必須對縫
牆、地磚空鼓率不能超過95%
磁磚碰口陰陽角的地方必須垂直
需要裁」7「字型磁磚必須現場裁、不能兩邊裁
專案經理
配合工人負責上料及鋪磚輔材
日常巡場
檢查驗收
六、木工工程施工
設計師 、專案經理、業主、施工人員到現場
設計師
設計師依施工圖向施工人員交底
設計師日常巡場
現場施工人員
依一米線放出需要施工的施工線
所有天花板角落全部"L"型整張石膏板
材料用輕鋼龍骨局部木龍骨
牆面打底出必須垂直過水平尺
專案經理
配合工人負責上料及鋪磚輔材
日常巡場
檢查驗收
七、膩子工程施工
設計師
設計師依施工圖向施工人員交底
設計師日常巡場
現場施工人員
刷防銹漆
用網子的確良布處理縫隙
用粉刷石膏整體找平
門口、窗口、踢腳板、衣櫃等地方全部用掛槓找平
陰、陽角需用陽角條
專案經理
配合工人負責上料及鋪磚輔材
日常巡場
檢查驗收
八、成品安裝工程
設計師
根據圖跟對應施工人員對接
設計師日常巡場
現場施工人員
門類安裝
櫃類安裝
牆布鋪貼
衛浴安裝
燈具安裝
專案經理
成品保護
日常巡場
檢查驗收
九、交工驗收
專案經理、設計師現場驗收
業主、專案經理、設計現場驗收
業主家與業主拍照留念
